| Model type |
URE295-72P |
| Peak power(Pmax) |
295W |
| Maximum power voltage(Vmp) |
36. 04V |
| Maximum power current(Imp) |
8.19A |
| Open circuit voltage(Voc) |
45.59V |
| Short circuit Current(Isc) |
8.74A |
| Cell efficiency |
17. 30% |
| Module efficiency |
15. 20% |
| Maximum series Fuse Rating |
15A |
| Maximum system voltage |
DC 1000V |
| Temp. Coeff.of Isc (TK lsc.) |
0.045%/°C |
| Temp. Coeff.of Voc (TK Voc) |
-0.34%/°C |
| Temp. Coeff. Of Pmax (TK Pmax) |
-0.47%/°C |
| Operating Temperature |
( – 40 – + 85%)°C |
| Normal Operating Cell Temperature |
45±2°c |
| Positive Tolerance |
0 – +3% |
| Cell type |
Poly Crystalline silicon,156mmx156mm |
| Number of the cells |
72 cells in series |
| Weight |
23Kg |
| Dimensions |
1956x992x50mm(77.01×39.06×1.97inch) |
| Front Glass |
3.2 mm tempered glass |
| Output Cables |
4 mm2, symmetrical lengths, 900 mm |
| Connectors |
MC4 compatible IP67 |
